The Knox Krypton 11000 is an 8KW hybrid solar inverter designed for larger residential or small commercial solar systems. With its advanced features such as built-in Wi-Fi for online monitoring and grid-tied integration, this inverter ensures efficient energy use and seamless operation.
The Knox Krypton 11000 is the perfect choice for users seeking a powerful, flexible, and efficient hybrid solar inverter that supports both residential and small commercial applications.
KNOX SERIES | Krypton 11000 |
MODEL |
HYBRID INFINI MAX II 8KW-48V TWIN |
Phase | Single Phase |
Maximum PV Input Power | 11000W (5500W x 2) |
Rated Output Power | 8000W |
GRID-TIE OPERATION | |
PV INPUT (DC) | |
Nominal DC Voltage / Maximum DC Voltage | 500 VDC |
Start-up Voltage / Initial Feeding Voltage | 120VDC / 150 VDC |
MPP Voltage Range | 90 ~ 450 VDC |
Number of MPP T rackers / Maximum Input Current | 27A x 2 (MAX 40A) |
GRID OUTPUT (AC) | |
Nominal Output Voltage | 220/230/240 VAC |
Output Voltage Range | 170-280 VAC (For Personal Computers) 90-280 VAC (For Home Appliances) |
Nominal Output Current | 35 A |
Power Factor | > 0.99 |
EFFICIENCY | |
Maximum Conversion Efficiency (DC/AC) | 95% |
OFF-GRID OPERATION | |
AC INPUT | |
AC Start-up Voltage / Auto Restart Voltage | 120 - 140 VAC / 180 VAC |
Acceptable Input Voltage Range | 90 - 280 VAC or 170 - 280 VAC |
Frequency Range | 50 Hz/60 Hz (Auto sensing) |
BATTERY MODE OUTPUT (AC) | |
Nominal Output Voltage | 220/230/240 VAC |
Output Waveform | Pure sine wave |
Efficiency (DC to AC) | 93% |
DC Voltage | 12 VDC ± 5%, 100W |
Transfer Time | 10 ms (For Personal Computers) ; 20 ms (For Home Appliances) |
BATTERY & CHARGER | |
Nominal DC Voltage | 48 VDC |
Floating Charge Voltage | 54 VDC |
Overcharge Protection | 66 VDC |
Solar Charger type | MPPT |
Maximum Solar Charging Current | 150A |
Maximum AC Charging Current | 120 A |
Maximum Charging Current | 150A |
Surge Power | 16000VA |
GENERAL | |
PHYSICAL | |
Dimension, D x W x H (mm) | 158.4 x 503.6 x 530.8 |
Net Weight (kgs) | 20 |
INTERACE | |
Parallel Function | YES, 6 units |
Communication Port | USB/RS232/RS485/Wifi/Dry-contact |
ENVIRONMENT | |
Humidity | 0 ~ 90% RH (No condensing) |
Operating Temperature | -10°C to 50°C |
Storage Temperature | -15°C to 60°C |
